Technical Specification:
Media:PE
Thickness:1.7mm
Unit Weight:500g/㎡
Operating temperature:130℃-150℃
Order(MOQ):
1Production：
|
500gsm antistatic polyester needle punched felt |
|
|
Construction |
Needle Felt |
|
Fibre Composition |
Polyester+Conductive yam |
|
Scrim Composition |
Polyester |
|
Felt Area Weight |
500g/m2 |
|
Thickness |
1.7mm |
|
Mean Air Permeability |
15(m3/m2/min@200pa) |
|
Breaking Strength-MD(warp) |
≥1100 |
|
Breaking Strength-CMD(weft) |
≥1500 |
|
Breaking Elongation(N/5cm)-MD (warp) |
≤35 |
|
Breaking Elongation(N/5cm)-CMD (weft) |
≤60 |
|
Dry shrinkage MD(130℃warp ) |
≤1.5 |
|
Dry shrinkage CMD(130℃weft ) |
≤1.0 |
|
Operating Temperatures |
≤130 deg C |
|
Recommended Maximum Continuous |
130 deg C |
|
Recommended Maximum Surge |
150 deg C |
|
Finish |
Heat set/singed/calendered |
Bag style:
round bag (steel belt style) flat bag, special-shaped bag, drawstring bag,
Filter bag head with thick felt, bottom reinforcement, bag body with iron ring,etc.
Advantages:
– Extra large filter surface pleated cartridge to replace filter bags without any modification.
– High flow and high contaminant holding capacity
– Unique filter medium which guarantees a very consistent performance
– Rigid pore construction prevents contaminant unloading at maximum differential pressure
– Inside-out flow traps particles inside the cartridge which prevents downstream contamination of the clean side during exchange
